750W Air Cooling Laser Welding Machine 220V Handheld Fiber Laser Cleaning System Description:
The FR-LA-20E 750W Air Cooling Laser Welding Machine is a compact and energy-efficient 4 In 1 Fiber Laser Welder designed for professional metal fabrication and industrial processing applications. This Hand Held Semi-Auto Air Cooling Fiber Laser Welding Multi-Function Machine integrates laser welding, laser cleaning, laser cutting, and laser derusting into one portable system, providing higher productivity and lower operating costs for modern workshops and manufacturing industries.
Equipped with an advanced air cooling system, the machine eliminates the need for bulky water chillers, making installation easier and maintenance more convenient. The 750W handheld fiber laser welder delivers stable laser output, smooth weld seams, minimal thermal deformation, and excellent welding precision. It is suitable for processing stainless steel, carbon steel, galvanized steel, aluminum, and other metal materials.
This portable fiber laser welding machine is widely used in sheet metal fabrication, hardware manufacturing, kitchenware production, automotive repair, advertising metal fabrication, stainless steel engineering, and industrial maintenance applications. Its lightweight structure, user-friendly operation, and multifunction capabilities make it an ideal solution for efficient metal processing and mobile welding projects.
750W Air Cooling Laser Welding Machine Specification:
| Model | FR-LA-15E | FR-LA-20E | FR-LA-25E |
| Power Supply | 1*220V, 50/60Hz | 1*220V, 50/60Hz | 1*220V, 50/60Hz |
| Rate Input Capacity (KVA) | 1.6 | 2.5 | 3.5 |
| Rate Input Current(A) | 7 | 11 | 15 |
| Laser Power | 500W | 750W | 1200W |
| Output power stability | 2% | 2% | 2% |
| Welding Depth of Fusion | 0.5-2.0mm | 0.5-2.5mm | 0.5-3.5mm |
| Laser spot Range | 0-8mm | 0-8mm | 0-8mm |
| Welding Speed | 0-120mm/s | 0-120mm/s | 0-120mm/s |
| Dia. of Wire | 0.8, 1.0 | 0.8, 1.0 | 0.8, 1.0 |
| Weight | 25kg | 28kg | 48kg |
| L*W*H(mm) | 560*240*460 | 560*240*460 | 600*250*570 |
750W Air Cooling Laser Welding Machine Feature:
- High-quality semiconductor laser and stable cooling system
- The torch has a special nozzle suitable for welding at different angles and positions on the workpiece
- The operation is easy and gets a high welding speed and high quality
- The efficiency can be up to 2-10 times that of TIG welding and can economize on manpower.
- General staff can use it, and no need for special training.
- You can fit a wire by a separate wire feeder system.
- Light hand torch and with 5m original Fiber
- Long life Accessories and save energy, lower use cost.
- Special safety protection function for welding workers.
- Laser model: continue or modulation
- Laser wavelength: 1080nm
- Cooling system: fan cooling
- Welding materials: steel/stainless steel/aluminum/copper.
- Multi-functions: welding, cutting, derusting, and weld seam cleaning.
- Smaller size and light weight, easy to move.
- Remote Style LCD control Panel.
Standard Accessories
Wire feeder
Torch 5m
Wire feeding hose
Protection Goggle
welding and cutting, cleaning nozzles
wire feed rollers
Optional Accessories
Torch and system: SUP21S, SUP23T
Twin-wire feeder system
